Fish Ball Machine

Technical Parameters of Fish Ball Making Machine
Model YW500A(with inverter) YW500 (without inverter)
Power 1.5KW 1.5KW
Capacity 500pcs/min 500pcs/min
Weighty 200KG 190KG
Material All stinless steel All stinless steel
Export Port FOB Xiamen, China FOB Xiamen, China
Overall Dimension 1000*400*1790(mm)
1000*400*1790(mm)

Fish Ball Making Machine



Fish ball making machine used to process fish ball, chicken ball, pork meatball and so on. There are different size mould to process different size fish ball. The ball it process is round and with good surface.



With certain rotating speed, the blade feeds paste to the cavity of forming gear continuously. Meanwhile, paste revolves along with the gear. With cup-shaped mould controlling the size of the ball, the reamer will make near-spherical balls regularly with even distribution of weight. According to the viscosity of the paste, the frequency converter can be modestly adjusted to regulate the speed of the machine and thus perfects the shape of ball.



Flow Chart

Type 1: Meat cutting machine-- Meat Grinding machine—Meat beating machine—meat ball  forming machine—Shape forming water tank--- Boiling tank---Cooling tank-Freezing-Packing

Type2: Meat cutting machine-Meat grinding machine-Meat mixing machine- Meat ball forming machine-First frying machine for forming shape- Second frying -Cooling tank-Freezing-- Packing



Notes
1. Application voltage environment should be given when making order, so as to choose the proper electric motor.
2. The warranty time for our fish ball making machine is 1 year, excluding belt. We offer charged maintenance services when warranty time is over.
3. Always wearing noise reduction earplug and hygienic uniform. Non-trained personnel are forbidden for machine operation.
